TRANSFORMATOR LAAG PROFIEL 25VA 2 x 7V / 2 x 1.667A
2070250MST
Bestellen
€ 28,50
incl. 21% BTW
Op voorraad in magazijnLevertijd: 2 tot 5 werkdagen
409
Aantal:
In winkelwagentje
Grotere aantallen nodig? Neem contact met ons op
Specificaties
Physical Properties |
Number of Outputs: |
Transformer Type: | Side Tag |
Elektrische Gegevens |
Nominale Uitgangsstroom: | 1.667 A |
Dielectric Strength: | > 5 kV |
Encapsulated Transformer Output Voltage Rating VAC: | 7.5 V |
Power Transformer: | 25 VA |
Beveiliging tegen Kortsluiting: | Neen |
Technische Gegevens |
Thermal Fuse Protection Possibility: | Yes |
Certifications: | According To BS 3535, VDE 0551, IEC 742 |
Type Montage: | Printplaat |
Omgevingsgegevens |
Werktemperatuur: | -20-70 °C |
Elektrische Aansluitingen |
Type Afsluitweerstand: | Soldeerpen |
Voeding |
Nominale Ingangsspanning VAC: | 230 V |
Nominale Ingangsfrequentie: | 50/60 Hz |
Basis Productinformatie |
Kleur: | Zwart |
Hoogte: | 49 mm |
Diepte: | 58.5 mm |
Breedte: | 94 mm |
Gewicht: | 740 g |
EAN-code
5410329259525
