WIMA 0.001µF 630V 18.5mm
0 WIMA 0.001µF 630V 18.5mm

Bestellen

€ 1,50 incl. 21% BTW
Op voorraad in magazijnLevertijd: 2 tot 5 werkdagen
305
Aantal:
In winkelwagentje

WIMA capacitors have reliable internal end terminations. They use a simple concept : the wire makes electrical contact with the complete surface of the electrode, which ensures minimal inductance. This results in capacitors with a good attenuation and self-resonance (see technical data and graphs).
Miniature type capacitors PCM 5mm.
Polypropylene film, film/foil.

Specificaties

pitch:18.5mm
max. werkspanning:630V
capaciteit:0.001µF
diëlektricum:polypropyleenfilm
elektrodes:metalen folie
behuizing:brandvertragend plastic, UL 94 V-0, met dichting in epoxy kleur :groen / merkteken :zwart
testspecificaties:volgens IEC 0384-2 en EN 130 800
testcategorie:55/100/56 volgens IEC
testspanning:2 Ur, 2 sec.
temperatuurbereik:-55°C tot +100°C
capaciteitstolerantie:± 10% (± 5%)

EAN-code

5410329296797
