CERMET TRIMMER MULTI-TURN 50K
CERMET TRIMMER MULTI-TURN 50K
0 CERMET TRIMMER MULTI-TURN 50K
1 CERMET TRIMMER MULTI-TURN 50K

Bestellen

€ 3,95 incl. 21% BTW
Op voorraad in de winkelVóór 17:00 besteld = morgen in huis!
8113
Aantal:
In winkelwagentje

Professional multiturn trimming potentiometers.
The cermet resistance element offers stability and high resolution. The trimmer is actuated by a screw with a slipping clutch at each end of travel. End stops are marked by an audible click. All units have a blue plastic case which withstands all recognised board washing solvents.

Kenmerken

  • MEC CITEC 443PW
  • horizontal mounting
  • horizontal adjustment
  • pin layout: triangle
  • bereik: 10E to 2M (E3 series)

Specificaties

vermogen:0.75W at 70°C
tolerantie:±10%
working voltage:400Vdc
rotatie:
elektrisch circuit:15 turns nom.
mechanisch:18 turns nom.
