CERMET TRIMMER MULTI-TURN 10K
CERMET TRIMMER MULTI-TURN 10K
0 CERMET TRIMMER MULTI-TURN 10K
1 CERMET TRIMMER MULTI-TURN 10K

Bestellen

€ 4,50 incl. 21% BTW
Op voorraad in de winkelVóór 17:00 besteld = morgen in huis!
8079
Aantal:
In winkelwagentje

Professional multiturn trimming potentiometers.
The cermet resistance element offers stability and high resolution. The trimmer is actuated by a screw with a slipping clutch at each end of travel. End stops are marked by an audible click. All units have a blue plastic case which withstands all recognised board washing solvents.

Kenmerken

  • MEC CITEC 4290W
  • vertical mounting
  • vertical adjustment
  • pin layout: line
  • bereik: 10E to 5M (E3 series)

Specificaties

vermogen:0.5W at 70°C
tolerantie:±10%
working voltage:300Vdc max.
rotatie:
elektrisch circuit:22 turns nom.
mechanisch:25 turns nom.

EAN-code

5410329755690
