INGEGOTEN TRANSFORMATOR 5VA 2 x 7.5V / 2 x 0.334A
2070050M
Bestellen
€ 12,95
incl. 21% BTW
Niet op voorraadInformeer naar de levertijd
404
Aantal:
In winkelwagentje
Grotere aantallen nodig? Neem contact met ons op
Direct antwoord?
Bel ons: 0485 - 35 03 63
Specificaties
Physical Properties |
Number of Outputs: |
Transformer Type: | Encapsulated |
Elektrische Gegevens |
Nominale Uitgangsstroom: | 0.334 A |
Beveiliging tegen Kortsluiting: | Ja |
Power Transformer: | 5 VA |
Dielectric Strength: | > 5 kV |
Encapsulated Transformer Output Voltage Rating VAC: | 7.5 V |
Isolation Resistance VDC: | > 5 megohm |
Technische Gegevens |
Maximum Temperature for Class E: | 95 °C |
Maximum Temperature Materials: | 120 °C |
Secondary voltage Maximum Voltage at 230V: | 7 % |
Secondary Voltage Minimum Voltage at 230V: | 3 % |
Thermal Class: |
Thermal Fuse Protection Possibility: | Yes |
Certifications: | Creepage Distances and Clearances According to IEC742 |
Type Montage: | Printplaat |
Omgevingsgegevens |
Maximale Omgevingstemperatuur: | 40 °C |
Elektrische Aansluitingen |
Type Afsluitweerstand: | Soldeerpen |
Voeding |
Nominale Ingangsfrequentie: | 50/60 Hz |
Nominale Ingangsspanning VAC: | 230 V |
Basis Productinformatie |
Kleur: | Zwart |
Hoogte: | 33 mm |
Diepte: | 37 mm |
Breedte: | 44 mm |
Gewicht: | 194 g |
EAN-code
5410329259440
